Proximity sensor for use in high vibration areas
The Shimpo MCS-3109 Proximity Sensor is complimentary (NPN-NO and NPN-NC) proximity sensor normally used in high-vibration areas and where a greater sensing distance is required
Features
- NPN (NO, NC) output
- 300 Hz frequency
- 0.32" (8 mm) sensing distance
- 6.5' (2 m) cable
- NEMA 6 (IP67) rating, for use in high vibration areas
Specifications
| Sensing Distance | 8 mm (0.32") |
| Activating Frequency | 300 Hz |
| Voltage Requirement | 10 – 30 VDC |
| Output Current | 100 mA |
| Housing | Nickel plated brass |
| Ambient Temperature | -25 to 70 °C (-13 to 158 °F) |
| Degree of Protection | IP67 / NEMA 4 |
