Tramex CME5 Concrete Moisture Encounter Non Destructive Moisture Meter

See More Tramex Moisture Meters

Tramex CME5 Concrete Moisture Encounter Non Destructive Moisture Meter

See More Tramex Moisture Meters
Price:
$570.00
    warrenty

    Product Description
    Tramex CME5 Concrete Moisture Encounter Non Destructive Moisture Meter
    Clear easy-to-read analog dial
    Instant and precise readings to a depth of approximately  3/4" into the slab.
    Reproducible and reliable results

    The Tramex CME5 Concrete Moisture Encounter is a non-destructive meter for measuring moisture content instantly in concrete slabs per ASTM F2659 and giving comparative or equivalent readings in other cementitious floor screeds. Easy-to-use, giving precise and repeatable results, the Concrete Moisture Encounter allows the user to make multiple tests over a large area in the shortest possible time.

    The Tramex CME5 Concrete Moisture Encounter detects and evaluates the moisture conditions within the slab or screed by non-destructively measuring the electrical impedance. A low frequency electronic signal is transmitted into the material under test via the electrodes in the base of the instrument. The strength of this signal varies in proportion to the amount of moisture present in the material. The Tramex CME5 Concrete Moisture Encounter determines the strength of the current and converts this to a moisture content value for concrete slabs and a comparative value for other cementitious floor screeds, displayed on a large clear analog dial.

    The Tramex CME5 Concrete Moisture Encounter also provides readings for gypsum floor screeds as well as comparative readings making this moisture meter suitable to perform a concrete moisture test as per ASTM F2659.


    line
    Kit Contents
    line

    The Tramex CME5 Concrete Moisture Encounter Non Destructive Moisture Meter includes everything needed for testing:


    line
    Features
    line

    Non-destructive in operation with no need to probe, drill or mechanically damage the surface.

    Clear easy-to-read analog dial.

    Instant and precise readings to a depth of approximately  3⁄4" into the slab.

    Bluetooth connection to accompanying IOS & Android App allowing for continual development and integration of apps and reporting.

    Hold function “freezes” meter reading when inspecting areas where the meter face is not visible, and for easy recording of data.

    Reproducible and reliable results.

    Spring-loaded contact pins compensate for uneven concrete and boost signal penetration.

    Rugged ergonomically designed enclosure.


    line
    Specifications
    line

    Size6.3" x 3.5" x 1.5" (160mm x 85mm x 38mm)
    Weight12.1oz (344g)
    ConstructionABS Body
    Power2 x AALR6 ALKALINE (included)
    DisplayAnalogue
    Depth of penetrationapprox. ¾" (20 mm)
    Moisture Content for Concrete0 to 6 %
    Comparative for Gypsum floor screed0 to 10
    Reference scale0 to 100


    line
    Mode Info
    line

    The Tramex CME5 Concrete Moisture Encounter is a top quality concrete moisture meter and an essential tool for non-destructive testing of concrete for professionals in the concrete coatings or flooring industry to help prevent moisture problems on concrete floors.

    The use of the Tramex CME5 Concrete Moisture Encounter can be extended with the optional Tramex CDK Concrete Determinator Moisture Probe which detects in-situ quantitative moisture content within the concrete down to an extendable depth of up to 4" (100mm).

    Moisture Mapping & Data Documentation

    Concrete moisture test results can be visualized with the Tramex Meters App and turned into moisture maps, reports and charts for sharing. Bluetooth connectivity to mobile devices also helps to GeoTag test results, create, save and share photos.

    Concrete Moisture Meter Design

    The Tramex Concrete Moisture Encounter CME5 detects and evaluates the moisture conditions within the slab or screed by non-destructively measuring the electrical impedance. A low frequency electronic signal is transmitted into the material under test via the electrodes in the base of the instrument. The strength of this signal varies in proportion to the amount of moisture present in the material. The Tramex CME5 concrete moisture meter determines the strength of the current and converts this to a moisture content value for concrete slabs and a comparative value for other cementitious floor screeds, displayed on a large clear analog dial.

    Concrete Moisture Meter - Operating procedure

    To carry out tests simply brush any dust from a smooth area of concrete and also from the electrodes, switch on the CME5 concrete moisture meter and place it firmly onto the surface, fully compressing the spring-loaded, signal-enhancing contacts on the base. Read the moisture content from the clear analogue dial. The Tramex Concrete Moisture Encounter CME5 is calibrated to give percentage moisture content readings on clean, bare dust free concrete floor slabs, with a depth of penetration of approx. ¾" (20 mm). Readings taken on concrete slabs through paint, coatings, adhesives or other materials on the surface should be regarded as qualitative or comparative and not quantitative.


    line
    Related Products
    line

    Tramex WDTK Water Damage Restoration Tech Kit

    • Industry: Water Damage Restoration
    related

    line

    Tramex CCTK Concrete Coatings Tech Kit

    • Industry: Flooring Inspection, Concrete Coatings, Water Damage Restoration
    related

    line

    Tramex FTK Flooring Tech Kit

    • Industry: Flooring Inspection, Flooring Installation
    related

    line

    Tramex CDK Concrete Determinator Moisture Probe

    • Providing In-Situ Moisture Content Readings In A Tramex Unified Moisture Content Test Method
    related

    line


    Tramex Accessory Pack for Concrete Moisture Encounter 5 and 5X

    • For use with CMEX5, CMEX2, MRH3 & PTM.
    • Order Code: HH14TP30 (For use with CMEX2, MRH3 and PTM)
    • Order Code: HH14TP30B (For use with CMEX5)
    related

    line

    Tramex CALCRH Calibration Check for CME5, CMEX5

    • The Tramex CALCRH is a calibration check plate used to easily verify if moisture meters yield proper moisture readings, or if or needs to be sent to a calibration lab.

    related

    line

    Tramex CALCRH Calibration Check for CME5, CMEX5

    • Heavy-duty Pin-type Electrode with Cable and 3" pins for use with CMEX5, MRH3
    • Order Code: HH14SP90 For use with MRH3
    • Order Code: HH14SP90 For use with CMEX5
    related

    line

    Tramex ASTM F2170 Accessory Pack

    • Accessory Pack for RH testing
    • The AP-F2170-B for use with the: CMEX5 and DL-RHTX
    • The AP-F2170 for use with the: CMEX2 and MRH3
    related

    line


    Tramex Extension Handle for ME5, CME5 and CMEX5

    • The Extension Handle can be used with the ME5CME5 and CMEX5 Moisture Meters. It is a useful accessory for measuring in out of reach, high places. It can also be used for taking readings on the floor and thus reduces the need for crouching or kneeling.
    • Order Code: E5-HBS
    related


    line
    Downloads
    line

    Tramex CME5 Concrete Moisture Encounter - Quick Guide
    Tramex CME5 Concrete Moisture Encounter - Instruction Manual
    Tramex CME5 Concrete Moisture Encounter - Data Sheet
    Tramex Meters App - Getting Started & Moisture Mapping
    Tramex Meters App - Visualizing, Photographing and Geo-tagging
    Accessories for Tramex Moisture Meters - Online Catalog
