Dakota Ultrasonics MX-5DL Data-Logging Ultrasonic Thickness Gauge

See More Ultrasonic Thickness Gauges
This product has been discontinued

Product Description

Advanced Ultrasonic Gauge measures a variety of materials

Range: 0.025 - 19.99 inches - 0.63 - 199.99 mm


Resolution: .001" (0.01 mm)

Alarm mode, Differential mode, high speed scanning, and data send

Measuring Range in Steel
0.040 - 8.00 inches
1.00 - 199.0 mm

The Dakota Ultrasonics MX-5DL Data-Logging Ultrasonic Thickness Gauge is a simple to operate Ultrasonic Thickness Gauge with an internal data logger. It offers features that make your job easier. An Alarm mode, Differential mode, high speed scanning, and data send are the main features of the MX-5 DL.

MX-5DL Data-Logging Ultrasonic Thickness Gauge will automatically log your readings in numeric order (1 to 1000 readings). The gauge comes as a complete kit, ready to use, and is backed by our 5 year limited warranty.

line
Features
line

  • Resolution of 0.001 inch (0.01 mm)
  • Large, backlit LCD display retains last reading
  • Simple operator controls virtually eliminate training
  • Special-purpose probes are offered for a variety of applications
  • Switch-selected units for inches or mm
  • CE Certified
  • For underwater surveying, probe cable lengths up to 50 feet are optionally
  • Differential Mode
  • Alarm Mode
  • RS232 output sends thickness readings to a printer, computer or other external storage device
  • Automatic numeric Data Logging system 1 to 1000 readings
  • Includes NIST Calibration Certificate

lineTypical Applicationsline

typical

lineMeasuring Limitsline

Minimum Radius for Convex Surfaces 0.350" (8.89 mm)
Minimum Radius for Concave Surfaces 3" (76.2 mm)
Minimum Headroom 1" (25.0 mm)
Minimum Sample Diameter 0.150" (3.8 mm)
Minimum Substrate Thickness - F na
Minimum Substrate Thickness - NFe na


lineSpecificationsline

Range in Steel 0.040-8.00" (1.00-199.9 mm)
Resolution .001" (0.01 mm)
Display 4½ - Digit, 0.5" Backlit LCD
Velocity Range 6,500-33,000 ft./sec (2000-10,000 m/sec.)
Probe 1/4", 5 MHz, actual wearface is 5/8" (17mm)
Cable 4 ft. (1.2 m) waterproof cable with non-polarized, quick-disconnect connectors. Optional lengths up to 50 ft. (15 m).
Temp. Limits Ambient: -20 to 120° F (-30 to 50° C)
Material: -0 to 200° F (-20 to 100° C
Special high temperature probes are optionally available.
Battery Type Two AA batteries
Battery Life 200 hours
Weight 7 ounces (196 g)
Size 2.5 x 4.5 x 1.25"
(64 x 114 x 32 mm)
Accessories Included Probe/cable assembly. 4 oz. bottle of coupling fluid, NIST Calibration Certificate, 2 AA batteries, operating instructions, hard-plastic carrying case.
Warranty Gauge: 5 Years
Probes: 90 Days


lineComplete Kitline

The MX-5DL Data-Logging Ultrasonic Wall Thickness Gauge is supplied as a complete kit with the gauge, probe, 4 oz. bottle of coupling fluid, 2 AA batteries, NIST Calibration Certificate, and Operating Instruction Manual - all in a foam-fitted carrying case

lineRelated Productsline

NIST-Traceable Steel Test Block
3 Sizes Available

  • Precision Machined and Finished
  • Includes NIST Report and Test Data

line

DataComm
Software for Thickness Gauges
ABQ

line

CF12
Coupling Fluid

  • Used to create an ultrasonic coupling between the probe and material to be measured
  • 12 oz Bottle

line

TICC-M
Protective Holder for Ultrasonic Gauges

  • Constructed from heavy duty Cordura Nylon
  • Built-in belt loop

line

V-Block
Transducer Holder

  • The V-Block transducer holder offers the operator greater control and repeatabily when measuring on pipes and other curved areas

line

TI-25-UW-50
50 Foot Underwater Probe / Cable Assembly

  • 50 Ft. Length, Waterproof Probe/Cable assembly with non-polarized, Dual-Lemo connectors

lineline


F.A.Q.

Do Dakota Ultrasonics Thickness Gauges require any training for use?

No. Dakota Ultrasonics Thickness Gauges are designed for simple operation and feature easy-to-use instruction manuals. We also provide technical support via telephone and/or email, and a 30-day money back guarantee.

Are Dakota Ultrasonics Thickness Gauges calibrated at the factory?

Yes. Dakota Ultrasonics Thickness Gauges arrive fully calibrated and ready to measure.

Do Dakota Ultrasonics Thickness Gauges include Certificate of Calibration?

Yes. Dakota Ultrasonic Thickness Gauges includes NIST-Traceable Calibration Certificate, CE-Certified

Can I measure the thickness of non-metallic materials like plastic and rubber with Dakota Ultrasonics Thickness Gauges?

Yes. Dakota Ultrasonics Thickness Gauges features several preprogrammed sound velocities for common materials.

Can Dakota Ultrasonics Thickness Gauges measure cast/ductile iron or cast aluminum?

Yes. Dakota Ultrasonics Thickness Gauges instruments are designed to accurately measure the wall thickness of carbon steel, aluminum, stainless steel and plastic.
