The DT-362 is a portable, line-powered stroboscope that utilizes super bright CREE High-Powered LED lamps
The Shimpo DT-362 AC-Powered LED Stroboscope (Universal Power) is a portable, line-powered stroboscope that utilizes super bright CREE High-Powered LED lamps. The DT-362's LED array provides a bright, stable strobe light over a wide measurement range with a lifetime far exceeding xenon-lit stroboscopes. Combined with a large, backlit LCD display, operation is simple with the 8-button keypad and quick rate-adjustment dial. Phase shift, flash duration, plus flash rate all are easily viewed and adjustable. The universal power range (85-240 VAC) allows one model to be utilized on various power voltages in a multitude of countries. The unit can function by user altered flash frequency or from a remote sensor's signal input which will automatically adjust the stroboscope to the corresponding process fluctuations.
The Shimpo DT-362 AC-Powered LED Stroboscope (Universal Power) is designed for speed and frequency measurements in motion and vibration analysis. It is ideal for predictive and preventive maintenance applications such as: motors, shafts, roto-gravure printing, extruders, blow molding, wire lettering and striping, engraving, pulse jets, water jets, fans, cams, gear teeth, belt inspections, fuel injectors, vibration analysis, spindle spinning, cutting blade timing and sharpness, plus many more in the printing, packaging, textile, automotive, cable, mining, steel, chemical, optical, medical and shipbuilding industries.
Kit Contents
- Shimpo DT-362 AC-Powered LED Stroboscope (Universal Power)
- Bottom and Top Handle
- 9.8' (3 m) power cable
- Carrying Case
Features
- LED technology greatly extends operation life and eliminates need to replace burned out bulbs
- Backlit LCD display aids usage while operating in dimly lit areas
- Easy adjustment with flash dial combined with x2/÷2 and fine tuning ± buttons enables precise flash setting
- Universal power capability from 85-240 VAC allows one model to handle a multitude of local power requirements
- Adjustable Flash Pulse duration achieves sharper images for detailed inspection
- Phase shift (in degrees of delay time) enables visual analysis of rotating or reciprocating objects through all points of motion/time/angle
- Flash rate may be synchronized with process speed with input from sensor or controller
- 1/4-20 UNC connection for permanent mount applications (remove bottom handle)
Specifications
| Flash Rate Range | 30 to 120,000 FPM; 1-2000 Hz |
| Accuracy | 0.01% ±1 digit of F.S. @ 77° F (25°C) |
| Lux Rating (Approx.) | 6000 FPM: Distance 8" (20 cm) 6850 lx with 10" (254 mm) irradiation dia., Distance 20" (50 cm) 2325 lx with 14" (355 mm) irradiation dia. 1500 FPM: Distance 8" (20 cm) 3395 lx with 10" (254 mm) irradiation dia., Distance 20" (50 cm) 1350 lx with 14" (355 mm) irradiation dia. |
| Lamp Lifetime | Approximately 3~5 years depending on usage. |
| Display | Backlit LCD |
| Resolution | 60 ~12,000 FPM = 0.1 FPM; 12,001~120,000 FPM = 1 FPM; 1~200 HZ = 0.01 Hz; 201~2000 = 0.1 Hz |
| Flash Duration | 0.1°- 2.5° |
| Power Requirement | 85-240 VAC 50/60Hz |
| External Sensor Input | Pulse Input; Mini-USB |
| Sensor Power Supply | 15 V dc up to 50 mA |
| Input Pulse Width | Over 50 μs |
| Input Signal Flash Delay | 0-999 ms; 0-359° |
| Temperature Limits | 32-95°F (0-35°C) |
| Humidity Limits | 35 to 85% RH |
| Enclosure | Aluminum & ABS |
| Product Weight | 1.8 lb (0.82 kg) |
| Package Weight | 5.3 lb (2.4 kg) |
| Dimensions | 8 x 4.3 x 7.6” (203 x 110 x 192 mm) |
| Approvals | CE, RoHS |
| Warranty | 1-Year |
| Included Accessories | Carrying Case, 9.8’ (3 m) power cable, Bottom and Top Handle |
