PS High Precision Mechanical Force Gauge

Price: $470.00

High Precision Mechanical Force Gauge

25 Ranges up 100lbs / 50 Kg / 500 N

Intrinsically Safe for use in hazardous environments

PS High Precision Mechanical Force Gauge

Accuracy of ± 0.2%
23 Ranges Available

Rugged construction and excellent accuracy make these force gauges ideal for tension and compression quality control measurements. Many ranges are offered, calibrated in Pounds, Kilograms, or Newtons.

Features

Ideal for push / pull measurements in all environments

Real Time force display with peak capture

Free manufacturer´s calibration report

Full set of accessories and carrying case included

Zero Tare Ring to zero the gauge in each position

Hand-held use or can be mounting a on test stand

ISO/IEC 17025 Long-form Certificate & Test Data is optionally available

2 Year Warranty

Photo Gallery - click any photo to enlarge

PS Complete Kit

Related Products

NIST CAL

Force Ranges

Model	Capacity (resolution)
PS-2	2 lb (0.01 lb)
PS-5	5 lb (0.025 lb)
PS-10	10 lb (0.05 lb)
PS-20	20 lb (0.1 lb)
PS-30	30 lb (0.2 lb)
PS-50	50 lb (0.25 lb)
PS-100	100 lb (0.5 lb)
PS-1KG	1 kg (5 g)
PS-2KG	2 kg (10 g)
PS-3KG	3 kg (20 g)
PS-5KG	5 kg (25 g)
PS-10KG	10 kg (50 g)
PS-20KG	20 kg (100 g)
PS-30KG	30 kg (200 g)
PS-50KG	50 kg (250 g)
PS-10N	10 N (0.05 N)
PS-20N	20 N (0.1 N)
PS-30N	30 N (0.2 N)
PS-50N	50 N (0.25 N)
PS-100N	100 N (0.5 N)
PS-200N	200 N (1 N)
PS-300N	300 N (2 N)
PS-500N	500 N (2.5 N)

<> <>

Displacement at full scale capacity is 10mm

Complete Kit


The complete kit includes the gauge, five measuring tips including; flat head, cone, chisel notched, small hook, large hook,Y-hook and three inch extension rod and instruction manual -- all supplied in a fitted hard plastic carrying case.
